TRANSPORTATION INDUSTRY
Sheet Metal Manufacturing
for Rail and Bus OEMs
TRUSTED BY
Alstom
Prevost
Nova Bus
Wabtec
Transportation programs depend on consistent, repeatable sheet metal parts, interior and exterior panels, access covers, housings, and interface components, built to fit the same way across recurring production lots.
Graphie manufactures precision sheet metal components and ready-to-integrate subassemblies, with integrated fastening hardware and permanent identification when required. Graphie supports long-standing transportation programs for OEMs such as Alstom, Prevost, Nova Bus, and Wabtec, work that requires controlled processes, lot traceability, and supplier audit readiness.
Transportation
manufacturing
constraints
Dimensional Repeatability
Dimensional repeatability across recurring lots and revisions
Fit-Up Consistency
Fit-up consistency for panels, cutouts, hardware and mounting points
Controlled
Documentation
Controlled documentation for inspections and lot history
Durable Identification
Durable identification that stays legible through service life
Sheet metal components
integrated in rolling stock and buses
Graphie typically manufactures items such as:
Interior and exterior body panels (stainless, aluminum, steel)
Access panels, removable covers, protective plates
Perforated panels (ventilation and protection)
Electrical/control housings and equipment covers
Brackets and mounting supports with integrated hardware (PEM® inserts, studs)
Operator interface panels and control fronts with aligned identification
Serialized ID plates and durable asset marking (program-dependent)
ISO 9001:2015
Certified
Quality systems, traceability &
process control
Graphie operates under ISO 9001:2015 certification and CWB W47.1 certification (processes and welders). For new parts, First Article Inspection is completed and retained; PPAP is available upon request.
Integrated identification
for fleet service life
For transportation equipment, identification must stay readable through cleaning, abrasion, and extended service cycles. Graphie integrates identification within the same workflow.
Marking & Engraving Laser
Mechanical Engraving
Serialization
Metalphoto
Manufacturing location
& service territory
Graphie operates from La Pocatière supporting OEM programs across Québec, Canada and the United States.
Québec
Canada
United States
